Meet Quipu: The Universe’s Largest Superstructure



Astronomers have just identified an enormous new cosmic structure – the largest ever reliably measured – stretching across more than a billion light-years. Dubbed Quipu, this network of galaxy clusters extends roughly 1.3–1.4 billion light-years in length and contains dozens of galaxy clusters bound by gravity and dark . To put this in perspective, Quipu is over 13,000 times longer than the Milky Way galaxy, and its mass (about 200 quadrillion times the Sun’s mass) makes it far heftier than any previously known structure. The discovery, announced in early 2025, gives astronomers a breathtaking new glimpse of the cosmic web on the grandest scales.



What Are Cosmic Superstructures?





The large-scale universe is not a random scattering of galaxies, but a vast





cosmic web of filaments, walls, and voids. Galaxies gather in groups and clusters, and those clusters in turn lie along long filaments of dark matter and gas. NASA describes the result as a “scaffolding” of twisting threads: each bright “node” (a galaxy cluster) sits at the junction of filaments, while huge empty voids occupy the gapsscience.nasa.gov. These interconnected features are often called superclusters or galactic walls. For example, the Sloan Great Wall (a filament of galaxies discovered in 2003) spans about 1.4 billion light-years, and the earlier Coma (CfA2) Great Wall is on the order of half a billion light-years. These mega-structures – each containing tens to hundreds of galaxy clusters – represent the largest “beads” and “threads” in the cosmic tapestry. In this context, Quipu is an even grander filament that weaves a new and larger thread into the cosmic web



Discovery of the Quipu Superstructure



In early 2025, a team led by Hans Böhringer (Max Planck Institute for Extraterrestrial Physics) announced the finding of a remarkable new cosmic filament. Using data from the ROSAT X-ray telescope, the researchers mapped hundreds of galaxy clusters in the nearby universe (roughly 425–800 million light-years from Earth). Galaxy clusters – each containing hundreds or thousands of galaxies – glow brightly in X-rays due to their hot intracluster gas, making them excellent tracers of massive structures. The team applied a “friends-of-friends” algorithm to link clusters that lie within a certain distance, effectively grouping clusters into larger structures. In doing so, they identified five enormous superstructures. The longest and most striking of these was given the name Quipu, after the knotted-string record-keeping device used by the Inca. (The cosmic structure’s pattern of one long “cord” with many offshoots resembles the Incan quipu strings.





The map above (from Böhringer et al. 2025) shows the five new superstructures.



identified in the survey Quipu is highlighted in red (marked “1”), while the other four – Shapley, Serpens–Corona Borealis, Hercules, and Sculptor–Pegasus – are colored blue, green, purple, and beige. In each case, the researchers found that many galaxy clusters line up in a filamentary network. According to the discovery paper, Quipu and its siblings together contain roughly 45% of all galaxy clusters and 30% of galaxies in the mapped volume. Quipu itself stood out as a prominent structure in the data – so obvious that Böhringer says “it immediately catches the eye” By following the ROSAT X-ray signals, the astronomers effectively traced the underlying dark matter web: as they note, “X-rays trace the densest regions of matter concentration and the underlying cosmic web”





Size and Composition of Quipu



Quipu’s sheer scale is staggering. The filament’s length is estimated at about 400 megaparsecs (roughly 1.3–1.4 billion light-years). Its structure is made up of at least 68 galaxy clusters (nodes along the filament) linked together. In mass, this system is on the order of 2×10^17 solar masses – about 200 quadrillion Suns. Most of this mass is dark matter; as the Max Planck press release explains, Quipu “consists mainly of dark matter”, with the visible galaxies and hot gas sitting in the densest knots. For scale, this means Quipu’s length is over 13,000 times the diameter of our Milky Way. The discovery team reports that Quipu (and the other four structures) collectively occupy about 13% of the surveyed volume, yet encompass ~25% of the total mass in that region Such a concentration shows that Quipu is not a rare isolated thread, but part of a network dominating the local cosmic landscape.



Comparisons with Other Giant Structures



How does Quipu compare to the giants we already knew? Historically, the Sloan Great Wall (discovered 2003) was considered the largest known filament. NASA notes that the Sloan Wall spans about 1.4 billion light-years, roughly the same order as Quipu. In fact, Princeton astrophysicist J. Richard Gott (leader of the Sloan Wall discovery) comments that “the Quipu superstructure, end to end, is slightly longer than the Sloan Great Wall”. Another famous nearby structure is the Shapley Supercluster (sometimes called a “great attractor” region), which is a few hundred million light-years across – much smaller than Quipu. By contrast, some distant structures dwarf even Quipu: for example, the Hercules–Corona Borealis Great Wall (mapped via distant gamma-ray bursts) is estimated to stretch 10 billion light-years or more. However, that “Great Wall” is seen only indirectly and is not confirmed as a single connected entity. As Max Planck’s Böhringer emphasizes, Quipu is the largest such structure in the nearby universe and in terms of directly observed galaxy clustersearth. In summary, Quipu surpasses the Sloan Wall and all previously cataloged superclusters in size (within the surveyed volume), though it remains far smaller than the speculative most-distant filaments.







For historical perspective, astronomers first mapped a “Great Wall” in the late 1980s. The CfA2 (Coma) Great Wall – shown above – extends on the order of 300–500 million light-years. A 2004 Hubble Ultra Deep Field image (used above) shows a small patch of the sky with thousands of galaxies, illustrating the kinds of building blocks (galaxies and clusters) that make up these walls. Every few decades, larger walls have been found: the Sloan Wall (1.4 billion ly), then Quipu (1.3–1.4 billion ly). Each new discovery pushes the envelope of the cosmological principle, which assumes the universe should look roughly uniform on the largest scales.



Cosmological Implications



The existence of Quipu and similar mega-structures has sparked discussion about our cosmological models. On one hand, the ΛCDM (“Lambda Cold Dark Matter”) standard model does predict large filaments and walls. Böhringer et al. note that simulations produce superstructures akin to Quipu, so such features are not forbidden. On the other hand, Quipu is so vast that it tests assumptions of homogeneity. The traditional cosmological principle holds that when averaged over sufficiently large volumes, matter should be smoothly distributed. Clusters like Quipu seem to break this symmetry locally: as one science writer puts it, large clumped walls “violate the cosmological principle” because they cause huge matter inhomogeneities. In practice, cosmologists are debating the issue. Böhringer and others argue that if one looks at an even larger cosmic volume, the universe indeed “reappears homogeneous” on average. In other words, Quipu may be a rare regional lumpiness, not a fatal flaw in ΛCDM.



Regardless, Quipu has tangible effects on observations. Its enormous mass bends space and light: galaxies behind it could be subtly gravitationally lensed, and the structure’s gravity can imprint on the cosmic microwave background via the Integrated Sachs–Wolfe effect. In addition, the bulk motion (streaming) of galaxies into Quipu can shift local measurements of the Hubble expansion rate. The discovery team points out that to make precision measurements of cosmological parameters, one must account for these local mega-structures. In summary, Quipu (and its four companion walls) contain a quarter of the mass in their region and so significantly influence the cosmic environment. While such structures will eventually drift apart as the universe expands, for now they serve as natural “laboratories” for testing how gravity and dark matter shape galaxies over time.



Expert Commentary



Astronomers have met the discovery of Quipu with keen interest. J. Richard Gott (Princeton) – who co-discovered the Sloan Great Wall – congratulated the team, noting that their find “is slightly longer than the Sloan Great Wall,” and joking, “Congratulations to them for finding it. His response underscores that Quipu’s measured length indeed eclipses the previous record. Hans Böhringer himself stresses that Quipu is the largest structure mapped so far in the nearby universe, but he expects still larger ones to be found as surveys probe deeper. Some caution is advised: as one commentator notes, if parts of such a wall are not gravitationally bound, their galaxies will eventually drift apart, so it may not remain a single “object” forever.

Overall, the tone is enthusiastic but measured. Böhringer told reporters that the structure was “very apparent” in the data, meaning the discovery was clear-cut. He and co-authors argue that previous studies were often too limited in volume, and that looking at Quipu’s scale is crucial for understanding cosmology. In the words of their paper, Quipu and its cousins deserve “special attention” as unique cosmic environments. Other astronomers (writing in outlets like New Scientist and Boing Boing) have echoed that sentiment, noting that while these giant walls are surprising, they appear consistent with known physics once larger scales are considered. In sum, the discovery has been greeted as an exciting confirmation that the cosmic web still has new strands to reveal.



Visualizing the Discovery



• Cosmic Web Diagram: A useful illustration would show the large-scale cosmic web, with filaments connecting clusters. Quipu could be highlighted along one filament. This helps readers see how galaxy clusters (nodes) and filaments form a three-dimensional network.



• Size Comparison Chart: A graphic scaling Quipu against known objects – for example, drawing Quipu next to the Sloan Wall, the Milky Way, and smaller structures – would clarify its immense length. (Space.com notes Quipu is >13,000 times the Milky Way’s diameter.)



• Telescope Images of Clusters: Including real or simulated images of rich galaxy clusters (from optical or X-ray telescopes) can show the reader what the “knots” of Quipu look like. For instance, a Hubble deep-field mosaic or an X-ray image of a cluster (like the Perseus Cluster) illustrates the scale of individual components.



• Sky Map of Superstructures: The diagram at the top of this page (above) itself serves as a visual aid, marking Quipu and four other nearby walls on an all-sky projection. Such a map contextualizes Quipu among other structures.



Each of these visuals would complement the text by translating numbers into images. (Note: actual figures such as the five-structure map and the Hubble image are embedded above for illustration.)



Conclusion: A New Frontier in Cosmic Mapping



The discovery of the Quipu superstructure is a milestone that enriches our picture of the universe. It shows that even the “nearby” universe (hundreds of millions of light-years out) contains still-larger patterns of galaxies than were previously known. Future surveys and telescopes – from advanced X-ray surveys to deep optical mappings – may reveal yet bigger structures or further detail within Quipu. For example, European Space Agency’s Euclid mission and the Vera C. Rubin Observatory will map billions of galaxies, helping astronomers trace filaments even more completely. Studying Quipu will also inform how galaxies evolve in dense cosmic environments and how such walls influence cosmological measurements.



In theoretical terms, Quipu will become part of how we validate the standard model of cosmology. The fact that ΛCDM simulations produce similar superstructures suggests our models can accommodate Quipu’s existence. Yet the scale of this structure – forming about 10% of the surveyed universe’s width – ensures it will be a key test case for ideas about homogeneity. As the authors note, superstructures like Quipu are “transient configurations” that will eventually fragment, but for now they are special physical entities that challenge us to understand the cosmos on its grandest scales.



In summary, Quipu may hold the title of “largest structure” today, but in astronomy that title is always provisional. For now, Quipu offers both a humbling reminder of the universe’s immensity and a concrete target for future observations. Its discovery highlights how much there still is to map in the cosmic web – a vast tapestry of which we have just uncovered a new, awe-inspiring thread.









Sources: Details above are drawn from the recent research by Böhringer et al. (2025) and associated reportsmpg.despace.comphys.orgboingboing.net, as well as background on known structuresscience.nasa.govapod.nasa.gov and expert commentarysmithsonianmag.comearthsky.org. Each claim is supported by published findings and news coverage.
